Pin Layout        1 Vpp

12-pin HEIDENHAIN flange socket or coupling
5 6 8 1 3 4 12 10
A B R 5 V
(UP) 		0 V
(UN)
+ – + – + –
Brown Green Gray Pink Red Black Brown/ White/
Green Green
  IEC 742 EN 50 178

2 11 7 9 /
5 V
Sensor		 0 V
Sensor 		Vacant Vacant Vacant
Blue White Violett / Yellow
      The sensor lines are connected internally to the respective supply lines.
Shield in housing.
