STEEL STRAIGHT EDGES

PROUDLY MADE IN OUR FACILITY IN THE U.S.A.

Straight Edge Group
  • Extremely accurate reference line.
  • Can be used for checking surfaces for straightness.
  • Precision ground and finely finished.
  • Perfect for drawing or scribing straight lines.
  • Graduated & non-graduated models available.
  • Stainless steel models longer than 24" have hang-up hole.
  • Tolerance 0.0005" per foot.
TOOL STEEL

Tool Steel 1/32 Graduations Beveled Edge


MODEL # LENGTH WIDTH THICKNESS WT (#)
SE-24-TSBG 24" 1-13/32" 11/64"   3
SE-36-TSBG 36" 2-13/32" 7/32" 12
SE-48-TSBG 48" 2-13/32" 7/32" 17


Tool Steel Non-Graduated Square Edge


MODEL # LENGTH WIDTH THICKNESS WT (#)
SE-12-TS 12" 1-13/32" 11/64" 2
SE-24-TS 24" 1-13/32" 11/64" 3
SE-36-TS 36" 2-13/32" 7/32" 12
SE-48-TS 48" 2-13/32" 7/32" 17
SE-72-TS 72" 3-5/32" 9/32" 36
SE-96-TS 96" 3-1/4" 5/16" 51


Tool Steel Non-Graduated Beveled Edge


MODEL # LENGTH WIDTH THICKNESS WT (#)
SE-12-TSB 12" 1-13/32" 11/64" 2
SE-24-TSB 24" 1-13/32" 11/64" 3
SE-36-TSB 36" 2-13/32" 7/32" 12
SE-48-TSB 48" 2-13/32" 7/32" 17
SE-72-TSB 72" 3-5/32" 9/32" 36
SE-96-TSB 96" 3-1/4" 5/16" 51
SE-120-TSB 120" 3-1/4" 5/16" 64
STAINLESS STEEL

Stainless Steel Non-Graduated Beveled Edge


MODEL # LENGTH WIDTH THICKNESS WT(#)
SE-12-SSBHD 12" 1-1/2" 3/16" 2
SE-24-SSBHD 24" 2" 3/16" 4
SE-36-SSBHD 36" 2" 1/4" 12
SE-48-SSBHD 48" 2-1/2" 1/4" 18
SE-60-SSBHD 60" 3" 1/4" 28
SE-72-SSBHD 72" 3" 1/4" 34
SE-96-SSBHD 96" 3-1/4" 5/16" 51


Stainless Steel Non-Graduated Square Edge


MODEL # LENGTH WIDTH THICKNESS WT (#)

SE-12-SSHD

12" 1-1/2" 3/16" 2
SE-24-SSHD 24" 2" 3/16" 4
SE-36-SSHD 36" 2" 1/4" 13
SE-48-SSHD 48" 2-1/2" 1/4" 19
SE-60-SSHD 60" 3" 1/4" 29
SE-72-SSHD 72" 3" 1/4" 35
SE-96-SSHD 96" 3-1/4" 5/16" 53








Automation and Metrology 130 Liberty Street Painesville, Ohio 44077
Phone:  (440) 354 6436  Fax:  (440) 639 9983
E-mail: sales@auto-met.com

Back


SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
