ROUND PERMANENT MAGNETIC CHUCKS

PROUDLY MADE IN OUR FACILITY IN THE U.S.A.
RMC-6-FP Round Permanent Magnetic Chuck
  • Permanent ceramic magnets for superior holding power, never lose their strength.
  • Back surface of the aluminum chuck body has tapped holes and turned counterbore for convenient mounting on machines.
  • All models are watertight except the RMC-5, which uses the swing-type on-off method.
  • Standard pole models have 1/4" poles & 1/8" separators.  Fine pole models have 1/8" poles & 1/8" separators.


STANDARD POLE


MODEL DIAMETER HEIGHT COUNTER-BORE BOLT CIRCLE TAPPED HOLES WT(#)
DIAMETER DEPTH

RMC-5
RMC-6
RMC-9
RMC-12
RMC-15
RMC-16
RMC-20

5-1/2"
6-1/4"
9-1/4"
12-1/4"
15-1/4"
16"
20" 		2-13/16"
2-15/16"
2-15/16"
2-15/16"
3-3/4"
2-15/16"
4-1/8" 		3"
3"
4"
4"
6"
6"
11" 		1/8"
1/8"
3/16"
3/16"
1/4"
3/16"
1/4" 		4"
4"
5"
5"
7-3/8"
9"
12-13/32" 		(4) 1/4-20
(4) 1/4-20
(4 )3/8-16
(4) 3/8-16
(6) 5/16-18
(6) 3/8-16
(6) 3/8-16 		15
17
36
60
120
96
205



FINE POLE


MODEL DIAMETER HEIGHT COUNTERBORE BOLT CIRCLE TAPPED HOLES WT(#)
DIAMETER DEPTH

RMC-6-FP
RMC-8-FP
RMC-10-FP
RMC-12-FP

6-1/4"
7-3/4"
10"
12-1/4" 		2-15/16"
2-15/16"
2-15/16"
2-15/16" 		3"
4"
4"
4" 		1/8"
3/16"
3/16"
3/16" 		4"
5"
5"
5" 		(4) 1/4-20
(4) 3/8-16
(4) 3/8-16
(4) 3/8-16 		18
26
43
62


!!!!!     FOR IMPORTANT HOLDING POWER INFORMATION CLICK HERE     !!!!!
