P1-5BS
Touch Trigger Probe
with Body & Shank


Not show actual size! O.D. is just 22mm - L=42mm

Fowler's new P1-5BS is a universal CMM Touch Trigger Probe including Body and Shank. Ideal for both manual and computer controlled CMM's, the P1-5BS has 3 led illuminators to indicate probe hits, can accept a variety of shank sizes and is compatible with any M2 probe styli.

Made in the USA, the P1-5BS is 5-Way and measures in X, Y and +Z axes, and has industry standard TTP output.


Fowler P1-5BS Probe Features:

5-Axis: measures in X, Y and +Z axes
Deviation: 1um - Repeatability: 0.5um
Stylus force: 9 grams
Over travel: XY 15, +3.0mm
Probe Status Indicator: 3 Green LED (120 spaced)
Shank mounting: 3/8", 14mm, 20mm, Special
Styli mounting: M2 Thread
Output: TTP compatible (Standard)
Connector: 5 Pin DIN (180)
Dimensions: OD: 20mm Length: 42mm + S


Side view clearly shows 5-pin DIN connector and 120 LED placement... Styli not included!


If you would like more information or a flyer on the CMM Probes, simply fill out our Information Request Form, or contact our office. Click here to view PDF - Right click to download
