Quadra-Chek digital readouts support industries that call for precise measurement and inspection of 2D and 3D parts. The products exhibit an intuitive user interface and simple, meaningful visual displays. Their design reflects a deep understanding of user needs. Metronics digital readouts lead the precision inspection industry with innovations that improve operator productivity, reduce errors and save time and money.


The new Gage-Chek is a multi-channel metrology display that accepts up to eight discrete inputs. It features intuitive visual displays, helpful audio cues and user-defined formulas. It also reports dynamic Min/Max measurements, provides SPC analysis from an integrated database and includes connectivity to PCs and other peripherals.
		Visual feedback A highly visible, intuitive and familiar interface with standard color cues. Instantly informs operators of pass/fail performance details for critical part dimensions.
		Integrated SPC database Store, retrieve and manage enormous amounts of measurement data on the shop floor. Check quality control of each gage. Share information locally and globally.
		Formulas Apply math formulas on up to 16 output dimensions for complex measurment solutions.

Download the Gage-Chek Metrology Display brochure This link will begin an automatic download of the Gage-Chek Metrology Display brochure in a Adobe Acrobat PDF file format. It presents the features, configuration options and specifications for the GC-100 Series products in detail. PDF files are read with Acrobat Reader, a software utility available from Adobe. (If your browser is equipped with the Reader plug-in, the PDF file will automatically open in this window. To save the PDF, click the disk icon in the toolbar and specify a target disk.) The brochure PDF is a 56K file. To receive a print version of this same document, click here to complete a literature request form.

The unique Quadra-Chek interface seamlessly incorporates the best tools and annotation conventions of previous Quadra-Chek products, reducing operator training time. Fast, familiar tools improve productivity and enhance measurement consistency throughout the entire measurement process. Learn more about innovations in Quadra-Chek Digital Readouts...

Re-designed Quadra-Chek digital readouts incorporate a range of ergonomic and display interface innovations that advance new standards for ease of use. See more...

QC-100
Quadra-Chek 100 Series Digital Readouts Flexible, compact and precise digital readouts for 1- to 4-axis measuring instruments. Ideal for measuring angular or linear dimensions. Can be used with inspection tools including optical comparators, measuring microscopes and coordinate measurement machines. Shown with optional remote keypad.
QC-200
Quadra-Chek 200 Series Geometric Readouts Our original digital readouts with a fresh new interface and sleek design. A time-saving measurement tool with patented Measure Magic® technology. Ideal for measuring 2D features. Can be used with inspection tools such as optical comparators, measuring microscopes and video measurement machines.

Download the Quadra-Chek Digital Readout brochure Click on the brochure at the left to begin an automatic download of the Quadra-Chek Digital Readout brochure in a Adobe Acrobat PDF file format. It presents the features, configuration options and specifications for the QC-100 and QC-200 Series products in detail. PDF files are read with Acrobat Reader, a software utility available from Adobe. (If your browser is equipped with the Reader plug-in, the PDF file will automatically open in this window. To save the PDF, click the disk icon in the toolbar and specify a target disk.) The brochure PDF is a 2MB file. To receive a print version of this same document, click here to complete a literature request form.
